A&S Power 12.8v 100ah Lifepo4 Battery for RV/solar storage/camper/AGV/Golf Cart/Marine/Yacht
- Art No :AS-IFR327004S17P
- Material:Lifepo4 battery
- Size :328*172*220mm
- Weight:13.1kg
- Description :
32700 4s17p 12.8v 100ah lifepo4 battery
1. Voltage:12.8v
2. Capacity:100Ah
3. Application: Home Storage/Solar Light/RV/Solar Storage/Camper/AGV/Golf Cart/Marine/Yacht
Specification:
A&S Power 12.8v 100ah Lifepo4 Battery for RV/solar storage/camper/AGV/Golf Cart/Marine/Yacht
32700 4s17p 12.8v 100ah lifepo4 battery
1.Voltage:12.8v
Product Description:
12v 100ah Lithium Ion Deep Cycle Battery
12V100Ah is the best-selling deep cycle lithium battery on the market, especially in caravan and sea voyages.
Unique performance and advantages, such as high energy density, long cycle life, environmental protection, and
safety, make more people choose this battery.Equipped with BMS and Bluetooth functions, which can help you
monitor the status of the battery at any time.
Parameter Table:
Electrical Characteristics | Nominal Voltage | 12.8v |
Nominal Capacity | 100Ah @ 0.2C | |
Energy | 1280Wh | |
Internal resistance | ≤45mΩ | |
Cycle Life | >2000 cycles @ 0.2c charge/ discharge at 100%DOD,End of life 70% capacity | |
Months Self discharge | ≤3.5% per month at 25ºC | |
Standard Charge | Charge voltage | 14.6±0.2V |
Charge Mode( CC/CV) | At 0ºC~45ºC temperature, charged to 14.6v at constant current of 0.2C5A, and then, changed continuously with constant voltage of 14.6v until the current was not more than 0.02C5A | |
Charge current | 20A | |
Max.Charge current | 50A | |
Standard Discharge | Discharge current | 20A |
Max.continuous current | 100A | |
Max. Pulse current | 200A (<3S) | |
Discharge cut-off voltage | 10.0V | |
Environmental | Charge Temperature | 0ºC to 45 ºC |
Discharge Temperature | -20ºC to 60 ºC | |
Storage Temperature | 0ºC to 45 ºC | |
Water Dust Resistance | IP55 | |
Mechanical | Cell & Method | IFR32700 N60,4S17P |
Plastic Case | ABS | |
Dimension (L*W*H*TH) | 328*172*215*220mm | |
Weight | Approx. 13.1KG | |
Terminal | M8 |
Features:
12v Lifepo4 Battery Manufacturers
Widely Applications For Lithium Battery 12v 100ah
The proprietary lithium iron phosphate chemistry of this battery makes it less of a hassle to maintain and utilize the power you need.
Not only are they designed to store power with ease, but they also provide you with lasting peace of mind, and their tremendous
durability makes it easy to use them at home, at work, or for your outdoor needs where trust, safety, and the environment matter most.
Widely used in caravan and camping, Backup Power, Electric Vehicles and golf cart, Floor Machines, Marine and boats, Recreational Vehicles, and Solar energy.
Main applications:
* Communication: back-up electric supply, interphone
* Eletric vehicles: electric bicycle (E-bike), golf cart , electric wheelchair, E-car and E-bus
* Power tools: electric cropper, electric drill, electric saw, electric hammer
* Illuminate devices: solar battery, miner lamp, solar power lamp, emergency light, electric torch.
* Portable office devices: Laptop, PDA, portable electrograph, portable printer
* Video devices: Portable DVD , portable television
* Others: R/C model, toy, small home appliance
Solar energy storage | Wind and solar energy storage | solar street light |
wind power | off-grid systems | Home energy storage |
Shenzhen A&S Power Technology Co.,Ltd
An OEM rechargeable battery manufacturer in China for over 15 years. Specializing in Lithium Polymer Battery, LiFePO4 Battery and Li-ion Battery Pack. Our batteries have got certifications such as UL, IEC62133, CB, CE, ROHS, and some models have also passed KC, BIS certification.
With the tenet of "People-oriented, Quality first and Keeping improving", we continue to improve quality, reduce costs and enhance services. We pay more attention to market changes, client needs, safety & environmental protection, and assume social responsibility.
A&S Power is dedicated to creating the life stage for employees and providing lithium batteries that are popular with customers all over the world.
With passion and faithfulness, we are committed to establishing a win-win business and striding forward to create a better future for your company.
--FAQ--
1. Q:Where can I get the price for 25.6V 6Ah Solar Powered 26650 LiFePo4 Battery Pack With IEC62133 ?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.
2. Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
3. Q: What about the lead time for mass production?
A: Honestly, it depends on your order quantity and the season you place the order. We suggested that you start inquiry to months before the date you would like to get the products at your country.
4. Q: What is your terms of payment?
A: We accept T/T and L/C.
5. Q: What is minimal rated capacity?
A: minimal rated capacity is the capacity on 0.2 C discharge till the voltage tapered to 2.0V shall be measured after rested for 30min then finish standard charge.
6. Q: What is internal impedance?
A: Internal impedance is measured at AC 1KHz after 50% charge.
7. Q: What is standard charge?
A: Charging shall consist of charging at a 0.2 C constant current rate until the cell reaches 4.20V. The cell shall then be charged at constant voltage 0f 4.20 volts while tapering the charge current Charging shall be terminat ed when the charging current has tapered to 0.02 C. Charge time:Approx 6.0h,The cell shall demonstrate no permanent degradation when charged between 0℃ and 45℃
8. Q: What is standard discharge?
A: Batteries shall be discharged at a constant current of 0.2 C to 3.0 volts @20℃±5℃. If no otherwise specified, the rest time between Charge and Discharge amount to 30min.
9. Q: What is overcharge?
A: After normal charge, test the batteries’ initial state and capacity. Charge to 10.0V at 3C, then charge at CV mode to 0.01C. Observe battery’s variation of appearance.
10. Q:What is over discharge?
A: After normal charge, test the batteries’ initial state. When the batteries are normal, Discharge to 0V at 0.5C. Observe battery’s variation of appearance.
11. Q: What is external short-circuit?
,A: After normal charge, test the batteries initial state, Keep the battery into explosion protection cover, short- circuit the positive and negative terminals directly (general resistance shall be less than or equal to 50mΩ). Sto p the test when the temperature falls to 10℃ lower than the peak value. Observe the variation of the batteries’ appearance and temperature.
