Specification:
A&S Power UL UN 483450 3.7v 850mah lithium polymer battery
Ratings
Item |
Rating |
Note |
||
3.1 Capacity |
Typical |
850mAh |
Discharge:0.2CmA cut off Voltage:3V for cell |
|
Minimum |
800mAh |
|||
3.2 Nominal Voltage |
Average 3.7V |
Discharge:0.2CmA cut off Voltage:3V for cell |
||
3.3 AC Impedance Resistance |
≤160mΩ |
|
||
3.4 Discharge Cut-off Voltage |
3.00V |
|
||
3.5 Charge Current |
160mA |
Standard Charge |
||
3.6 Charge Voltage |
4.2V |
|
||
3.7 Max. Charge Voltage |
4.23V |
|
||
3.8 Charge Time |
Approx 6.0h |
Charge: 0.2CmA |
||
3.9 Max. Charge Current |
800mA |
1.0CmA |
||
3.10 Max. Discharge Current |
800mA |
|
||
3.11 Weight |
Approx 16.0g |
|
||
3.12 Operating Temperature |
Charge |
0~+45℃ |
|
|
Discharge |
-20~+60℃ |
|
||
3.13 Storage Temperature |
less than 1 month |
-20~+45℃ |
Recommended storage temperature: 20℃,at the shipment state |
|
less than 3 months |
-20~+35℃ |
A&S Power Battery with Terminations, Pins, Tags
Battery is always available with different types of terminations, i.e. PC pins, tabs, solder tabs, leads, wire, cable and connectors. We hope you find the one in our product list and suite you the best. If not, our Customer Service can assist you to find one, or offer custom-made terminations to meet meet your specifications.
Custom Battery Pack
We manufacture custom battery pack assembly for electronic, industry and OEM business for decades. We are proud to serve our customers, some of them are world's most prominent companies, with engineering design, prototype, in-house testing, certifications, and mass-production. Our Customer Service can help for engineering suggestion to meet your specification.
A&S Power Battery Quality Control & Compliance
Check A&S Power Manufacturing site and product compliance.
Safety Handling and Product Design with A&S Power Lithium Battery
Handling Lithium Battery Safely
A&S Power Lithium Polymer Battery Model List With Certifications:
Model | Nominal voltage(V) | Capacity (mAh) | Thickness (mm) | Width (mm) | Length (mm) | Certification |
AS10100 | 3.7 | 58 | Diameter: 10 | 10 | CQC | |
AS08310 | 3.7 | 130 | Diameter: 8.0 | 31 | IEC62133, UN38.3 | |
AS17450 | 3.7 | 1100 | Diameter: 17 | 45 | IEC62133(CB), UN38.3 | |
AS10500 | 3.7 | 390 | Diameter: 10 | 50 | IEC62133(CB), UN38.3 | |
AS102040 | 3.7 | 700 | 10 | 20 | 40 | UL1642,CE,UN38.3 |
AS102231 | 3.7 | 600 | 10 | 22 | 31 | UL1642 |
AS103035 | 3.7 | 1000 | 10 | 30 | 35 | UL1642,CE |
AS103450 | 3.7 | 2000 | 10 | 34 | 50 | UL1642,CE,UN38.3 |
AS104049 | 3.7 | 2600 | 10 | 40 | 49 | UL1642,IEC62133(CB),CE,UN38.3 |
AS104065 | 3.7 | 3200 | 10 | 40 | 65 | UL1642,IEC62133(CB),CE,BIS,UN38.3 |
AS105073 | 3.7 | 5000 | 10 | 50 | 73 | UL1642,CE |
AS112560 | 3.7 | 1800 | 11 | 25 | 60 | UL1642 |
AS125099 | 3.7 | 3750 | 12 | 50 | 99 | UL1642 |
AS126363 | 3.7 | 5400 | 12 | 63 | 63 | UL1642,UN38.3 |
AS253550 | 3.7 | 360 | 2.5 | 35 | 50 | UL1642,IEC62133(CB) |
AS271420 | 3.7 | 20 | 2.7 | 14 | UL1642 | |
AS301320 | 3.7 | 55 | 3.0 | 13 | 20 | UL1642 |
AS302025 | 3.7 | 100 | 3.0 | 20 | 25 | UL1642 |
AS302323 | 3.7 | 110 | 3.0 | 23 | 23 | UL1642,UN38.3 |
AS302530 | 3.7 | 180 | 3.0 | 25 | 30 | KC |
AS303080 | 3.7 | 850 | 3.0 | 30 | 80 | UL1642,IEC62133,CE,UN38.3 |
AS3062173 | 3.7 | 3500 | 3.0 | 62 | 173 | UL1642 |
AS321129 | 3.7 | 70 | 3.2 | 11 | 29 | UL1642 |
AS351120 | 3.7 | 40 | 3.5 | 11 | 20 | UL1642,CE |
AS351121 | 3.7 | 45 | 3.5 | 11 | 21 | UL1642 |
AS352025 | 3.7 | 110 | 3.5 | 20 | 25 | UL1642,CE |
AS352730 | 3.7 | 220 | 3.5 | 27 | 30 | UL1642,CE |
AS356585 | 3.7 | 2000 | 3.5 | 65 | 85 | UL1642 |
AS357090 | 3.7 | 2800 | 3.5 | 70 | 90 | UL1642,CE |
AS371042 | 3.7 | 105 | 3.7 | 10 | 42 | UL1642 |
AS381018 | 3.7 | 40 | 3.8 | 10 | 18 | UL1642 |
AS391520 | 3.7 | 90 | 3.9 | 15 | 20 | UL1642 |
AS392265 | 3.7 | 510 | 3.9 | 22 | 65 | UL1642 |
AS400830 | 3.7 | 60 | 4.0 | 8 | 30 | UL1642,CE |
AS401020 | 3.7 | 55 | 4.0 | 10 | 20 | UL1642,CE |
AS401030 | 3.7 | 80 | 4.0 | 10 | 30 | UL1642,CE,UN38.3 |
AS401119 | 3.7 | 50 | 4.0 | 11 | 19 | UL1642 |
AS401120 | 3.7 | 60 | 4.0 | 11 | 20 | UL1642 |
AS401230 | 3.7 | 120 | 4.0 | 12 | 30 | UL1642,IEC62133(CB),KC,UN38.3,CQC |
AS401235 | 3.7 | 130 | 4.0 | 12 | 35 | UN38.3 |
AS401245 | 3.7 | 190 | 4.0 | 12 | 45 | CE |
AS401824 | 3.7 | 100 | 4.0 | 18 | 24 | KC |
AS402525 | 3.7 | 200 | 4.0 | 25 | 25 | CE,KC,UN38.3 |
AS403040 | 3.7 | 430 | 4.0 | 30 | 40 | UL1642,CE |
AS405070 | 3.7 | 1700 | 4.0 | 50 | 70 | UL1642,CE,UN38.3 |
AS405080 | 3.7 | 1750 | 4.0 | 50 | 80 | UN38.3 |
AS406868 | 3.7 | 2200 | 4.0 | 68 | 68 | UL1642,CE |
AS423040 | 3.7 | 530 | 4.2 | 30 | 40 | UL1642,UL2054,CE,KC,UN38.3 |
AS442030 | 3.7 | 210 | 4.4 | 20 | 30 | UL1642,CE |
AS443493 | 3.7 | 1500 | 4.4 | 34 | 93 | UL1642 |
AS451268 | 3.7 | 280 | 4.5 | 12 | 68 | UL1642 |
AS452428 | 3.7 | 250 | 4.5 | 24 | 28 | CE |
AS455060 | 3.7 | 1400 | 4.5 | 50 | 60 | UL1642,CE |
AS461730 | 3.7 | 200 | 4.6 | 17 | 30 | UL1642,CE,KC,UN38.3 |
AS481221 | 3.7 | 70 | 4.8 | 12 | 21 | UL1642,CE |
AS483450 | 3.7 | 850 | 4.8 | 34 | 50 | UL1642,CE,UN38.3 |
AS495892 | 3.7 | 3000 | 4.9 | 58 | 92 | UL1642 |
AS501235 | 3.7 | 160 | 5.0 | 12 | 35 | KC,UN38.3 |
AS502025 | 3.7 | 180 | 5.0 | 20 | 25 | UL1642,CE,KC |
AS502030 | 3.7 | 240 | 5.0 | 20 | 30 | UL1642,CE,KC,UN38.3 |
AS502248 | 3.7 | 500 | 5.0 | 22 | 48 | UL1642,IEC62133(CB),CE,UN38.3 |
AS503030 | 3.7 | 430 | 5.0 | 30 | 30 | UL1642,CE,KC |
AS503034 | 3.7 | 460 | 5.0 | 30 | 34 | UL1642,CE |
AS503035 | 3.7 | 500 | 5.0 | 30 | 35 | UL1642,CE |
AS504552 | 3.7 | 1200 | 5.0 | 45 | 52 | UL1642,CE |
AS505055 | 3.8 | 1800 | 5.0 | 50 | 55 | UL1642,UL2054,IEC62133(CB),CE,UN38.3 |
AS505771 | 3.7 | 2200 | 5.0 | 57 | 71 | UL1642,CE |
AS506077 | 3.7 | 3400 | 5.0 | 60 | 77 | UL1642,IEC62133(CB),CE,UN38.3 |
AS523450 | 3.7 | 1000 | 5.2 | 35 | 50 | UL1642,CE |
AS535058 | 3.7 | 1600 | 5.3 | 50 | 58 | UL1642,CE |
AS542435 | 3.7 | 500 | 5.4 | 24 | 35 | UN38.3 |
AS552035 | 3.7 | 350 | 5.5 | 20 | 35 | UL1642,UL2054,IEC62133(CB),CE,KC,UN38.3,WERCS |
AS552540 | 3.7 | 540 | 5.5 | 25 | 40 | UL1642,CE |
AS553345 | 3.7 | 720 | 5.5 | 33 | 45 | UL1642,CE |
AS553436 | 3.7 | 740 | 5.5 | 34 | 36 | UL1642,CE |
AS553444 | 3.7 | 650/950 | 5.5 | 34 | 44 | UL1642,CE,KC |
AS553640 | 3.7 | 850 | 5.5 | 36 | 40 | UL1642,UL2054,IEC62133(CB),CE,KC,UN38.3,CQC |
AS553759 | 3.7 | 1350 | 5.5 | 37 | 59 | UL1642,CE |
AS556585 | 3.7 | 3600 | 5.5 | 65 | 85 | UL1642 |
AS562438 | 3.7 | 400 | 5.6 | 24 | 38 | UL1642,CE |
AS583573 | 3.7 | 1500 | 5.8 | 35 | 73 | UL1642 |
AS584070 | 3.7 | 2000 | 5.8 | 40 | 70 | UL1642,UL2054,IEC62133(CB),CE,KC,UN38.3,PSE |
AS593545 | 3.7 | 1050 | 5.9 | 35 | 45 | CE |
AS601362 | 3.7 | 500 | 6.0 | 13 | 62 | UL1642,CE |
AS601530 | 3.7 | 250 | 6.0 | 15 | 30 | CE |
AS601470 | 3.7 | 600 | 6.0 | 14 | 70 | CE |
AS602025 | 3.7 | 200 | 6.0 | 20 | 25 | CE |
AS602030 | 3.7 | 300 | 6.0 | 20 | 30 | CE,KC |
AS602240 | 3.7 | 500 | 6.0 | 22 | 40 | UL1642,CE,KC |
AS602663 | 3.7 | 1000 | 6.0 | 26 | 63 | UL1642,IEC62133,CE,KC,UN38.3 |
AS603030 | 3.7 | 520 | 6.0 | 30 | 30 | UL1642,IEC62133(CB),CE,KC,UN38.3,WERCS |
AS603040 | 3.7 | 750 | 6.0 | 30 | 40 | UL1642,UL2054,IEC62133(CB),CE,KC,UN38.3,WERCS |
AS603048 | 3.7 | 900 | 6.0 | 30 | 48 | UL1642,CE,KC,UN38.3 |
AS603245 | 3.7 | 720 | 6.0 | 32 | 45 | UL1642 |
AS603450 | 3.7 | 1050 | 6.0 | 34 | 50 | UL1642,IEC62133(CB),CE,KC,UN38.3 |
AS603465 | 3.7 | 1350 | 6.0 | 34 | 65 | UL1642,CE |
AS603952 | 3.7 | 1400 | 6.0 | 39 | 52 | CE |
AS604050 | 3.7 | 1100 | 6.0 | 40 | 50 | UL1642,IEC62133(CB),UN38.3 |
AS606060 | 3.7 | 2500/3000 | 6.0 | 60 | 60 | UL1642,CE |
AS6060115 | 3.7 | 5000 | 6.0 | 60 | 115 | UL1642,CE |
AS623441 | 3.7 | 1000 | 6.2 | 34 | 41 | CE |
AS624046 | 3.7 | 1200 | 6.2 | 40 | 46 | UL1642,IEC62133(CB),CE,UN38.3 |
AS6482148 | 3.7 | 3750 | 6.4 | 82 | 148 | UL1642 |
AS652030 | 3.7 | 350 | 6.5 | 20 | 30 | UL1642,CE,KC,UN38.3 |
AS652631 | 3.7 | 520 | 6.5 | 26 | 31 | UL1642,CE |
AS653136 | 3.7 | 800 | 6.5 | 31 | 36 | CE |
AS682134 | 3.7 | 500 | 6.8 | 21 | 34 | UL1642 |
AS701235 | 3.7 | 250 | 7.0 | 12 | 35 | CE |
AS701729 | 3.7 | 300 | 7.0 | 17 | 29 | UL1642,BIS |
AS701416 | 3.7 | 100 | 7.0 | 14 | 16 | UL1642,CE |
AS701919 | 3.7 | 150 | 7.0 | 19 | 19 | UL1642,CE |
AS702040 | 3.7 | 500 | 7.0 | 20 | 40 | UL1642,IEC62133(CB),CE,UN38.3,WERCS |
AS703440 | 3.7 | 1000 | 7.0 | 34 | 40 | UL1642,UL2054,CE,KC,UN38.3 |
AS704060 | 3.7 | 1800 | 7.0 | 40 | 60 | UL1642,CE |
AS705088 | 3.7 | 3400 | 7.0 | 50 | 88 | UL1642 |
AS723272 | 3.7 | 1700 | 7.2 | 32 | 72 | UL1642 |
AS753048 | 3.7 | 1200 | 7.5 | 30 | 48 | UL1642,CE,KC |
AS755070 | 3.7 | 3000 | 7.5 | 50 | 70 | UL1642,IEC62133(CB),CE, KC |
AS802030 | 3.7 | 420 | 8.0 | 20 | 30 | UL1642,CE |
AS803035 | 3.7 | 800 | 8.0 | 30 | 35 | UL1642,UL2054,CE,KC,UN38.3 |
AS803040 | 3.7 | 900 | 8.0 | 30 | 40 | CE |
AS803648 | 3.7 | 1200 | 8.0 | 36 | 48 | UL1642,CE |
AS805052 | 3.7 | 2500 | 8.0 | 50 | 52 | UL1642 |
AS8051116 | 3.7 | 6900 | 8.0 | 51 | 116 | UL1642,CE |
AS853450 | 3.7 | 1500 | 8.5 | 34 | 50 | UL1642,CE,CB,KC,UN38.3 |
AS872237 | 3.7 | 750 | 8.7 | 22 | 37 | UL1642 |
AS904286 | 3.7 | 4000 | 9.0 | 42 | 86 | UL1642,CE |
AS954674 | 3.7 | 4050 | 9.5 | 46 | 74 | UL1642 |
AS962731 | 3.7 | 720 | 9.6 | 27 | 31 | UL1642 |
AS853450-2P | 3.7 | 3000 | 17 | 35 | 53 | UL1642,UL2054,UN38.3 |
Q1: Can I have some samples for testing quality?
A1: Yes, you can buy some samples of any our products for testing quality and market.A5: yes,we are factory.
Q6. Can you explain in detail how you match cells for a battery pack before you assembling the pack?
A6: We will do the following things before assembling the pack:
a. Select capacity, same capacities cells for one pack
b. Measure the voltage, same voltage cells for one pack(difference is under 0.02v per cell)
c. Measure the inner resistance,same IR cells for one pack (difference is under 1m Ohm)
All above steps are very strict to make sure the pack performance is perfect.
Q7: What&rsquos your advantage compared with other suppliers?
A7: a. High quality batteries: Our batteries are in enough capacity, and lower in RI,
Before shipment, we will inspect the products and ensure the quality which are well approved by our clients.
b. Better service: We always offer what our clients need. Reply client&rsquos questions timely. Supply best projects solution for clients. We ship out the products on time&hellip
