New room-temperature liquid-metal battery could be the path to powering the future
Source: University of Texas at Austin
Summary: Researchers have created a new liquid battery with components that can remain molten at room temperature. Other liquid batteries must be kept at 240 degrees Celsius for their components to stay molten.
Researchers in the Cockrell School of Engineering at The University of Texas at Austin have built a new type of battery that combines the many benefits of existing options while eliminating their key shortcomings and saving energy.
Most batteries are composed of either solid-state electrodes, such as lithium-ion batteries for portable electronics, or liquid-state electrodes, including flow batteries for smart grids. The UT researchers have created what they call a "room-temperature all-liquid-metal battery," which includes the best of both worlds of liquid- and solid-state batteries.Solid-state batteries feature significant capacity for energy storage, but they typically encounter numerous problems that cause them to degrade over time and become less efficient. Liquid-state batteries can deliver energy more efficiently, without the long-term decay of sold-state devices, but they either fall short on high energy demands or require significant resources to constantly heat the electrodes and keep them molten.
The metallic electrodes in the team's battery can remain liquefied at a temperature of 20 degrees Celsius (68 degrees Fahrenheit), the lowest operating temperature ever recorded for a liquid-metal battery, according to the researchers. This represents a major change, because current liquid-metal batteries must be kept at temperatures above 240 degrees Celsius.
"This battery can provide all the benefits of both solid- and liquid-state -- including more energy, increased stability and flexibility -- without the respective drawbacks, while also saving energy," said Yu Ding, a postdoctoral researcher in associate professor Guihua Yu's research group in the Walker Department of Mechanical Engineering. Ding is the lead author of a paper on the room-temperature battery the team published recently in Advanced Materials.
The battery includes a sodium-potassium alloy as the anode and a gallium-based alloy as the cathode. In the paper, the researchers note that it may be possible to create a battery with even lower melting points using different materials.
The room-temperature battery promises more power than today's lithium-ion batteries, which are the backbone of most personal electronics. It can charge and deliver energy several times faster, the researchers said.
Because of the liquid components, the battery can be scaled up or down easily, depending on the power needed. The bigger the battery, the more power it can deliver. That flexibility allows these batteries to potentially power everything from smartphones and watches to the infrastructure underpinning the movement toward renewable energy.
"We are excited to see that liquid metal could provide a promising alternative to replace conventional electrodes," Professor Yu said. "Given the high energy and power density demonstrated, this innovative cell could be potentially implemented for both smart grid and wearable electronics."
The researchers have spent more than three years on this project, but the job isn't done yet. Many of the elements that constitute the backbone of this new battery are more abundant than some of the key materials in traditional batteries, making them potentially easier and less expensive to produce on a large scale. However, gallium remains an expensive material. Finding alternative materials that can deliver the same performance while reducing the cost of production remains a key challenge.
The next step to increasing the power of the room-temperature battery comes in improving the electrolytes -- the components that allow the electrical charge to flow through the battery.
"Although our battery cannot compete with high-temperature, liquid-metal batteries at the current stage, better power capability is expected if advanced electrolytes are designed with high conductivity," Ding said.
Materials provided by University of Texas at Austin. Note: Content may be edited for style and length.
